Anatomy and Physiology: The 3D Human Brain

I've been told I have a weird way of looking at the body. I've likened the digestive system to a train route, the heart to a machine, and now I'm about to throw a bunch of computer jargon at you for the brain.

Think of your body as a computer. Mac or PC—doesn't matter. A computer is made up of tons of small wires (vasculature and nerves), parts (organs), and the tasks it performs come from the central processing unit, or CPU (brain). It takes a lot of digging to get to the CPU of a computer, so that's what we're going to do: we're going to dig.

If you have 3D Human Anatomy Atlas, feel free to call up the 3D brain model and follow along!



Muscles of Expression

Muscles of expression head brain

Every time you smile, frown, laugh, cry, or clench your teeth in anger, you are expressing an emotion. Some of these are involuntary—you react automatically when you find something funny or upsetting. It takes a lot of discipline to contain your emotions.

The muscles of expression allow you to show your emotions. They pull at your eyebrows and the corners of your mouth; they wrinkle your nose and chin; they furrow your forehead. And guess what—the brain is responsible for all of it.

When you laugh at a joke or cry during a sad movie, your brain interprets these emotions and uses your muscles to express them.



Cerebral Arterial Circle: Circle of Willis

Circle of willis brain arteries

Okay, so we peel back the cover of the computer (a.k.a., everything on the outside) and begin our descent.

Blood supply to the body's organs is obviously important, but blood supply to the brain is super important. Think of it as plugging in your laptop—you need a continuous power source to keep everything running.

Numerous branches of the Circle of Willis (the cerebral arterial circle) distribute blood throughout the brain and provide collateral circulation.

The thick, blue structure that rests above the two brain hemispheres is the superior sagittal sinus, which drains blood from the brain.



Functions of the Four Lobes of the Brain

Brain lobes frontal parietal occipital temporal

Here we go. Now we're in the "guts" of our computer, so to speak. The brain has two hemispheres. The largest part of the brain (what most people visualize when they think of the brain) is the cerebrum. In the image above I've highlighted sections of the four main lobes of the cerebrum: the frontal lobe, parietal lobe, temporal lobe, and occipital lobe; each are named for the bones with which they correspond.

  • The frontal lobe is the most anterior of the four, and it is responsible for functions including speech, long-term memory, and decision-making.
  • The parietal lobe integrates sensory information and plays a role in spatial perception. It processes awareness of the body's motion, touch, perception of temperature, and pain.
  • The temporal lobe contains an auditory cortex that receives input from the cochlear nerve, and association areas that integrate auditory, olfactory, and complex pattern perception.
  • The occipital lobe is the most posterior of the four; its functions include receiving input from the eye and processing visual perceptions.



Functions of the Hindbrain

Hindbrain rhombencephalon pons medulla oblongata cerebellum

Most people, when they picture the brain, only think of the cerebrum. There's much more to it than that!

The hindbrain, or rhombencephalon, is a large structure in the posterior region of the brain, inferior to the occipital lobe. It consists of the medulla oblongata, the pons, and the cerebellum. The cerebellum fine-tunes body movement and manages balance and posture. The medulla oblongata (which is just fun to say) acts as the conduction pathway between the spinal cord and the brain as it controls involuntary functions of the respiratory, digestive, and circulatory systems and contributes to hearing balance and taste. The pons bridges the two main function areas of the central nervous system, the "higher" brain centers and the spinal cord.



Functions of the Limbic System

Limbic system hippocampus fornix amygdala

The limbic system is made up of a number of structures that manage a range of emotions and contribute to the processing of memory and smell.

The hippocampus, one of the most recognizable structures of the limbic system, is made up of mostly gray matter and plays a role in the consolidation of long-term memory.



Functions of the Midbrain

Midbrain mesencephalon brain spinal cord

The midbrain, one of the main areas of the brain, is involved with vision, hearing, motor control, and thermoregulation.



So the next time you open up Solitaire or spend 18 hours on Facebook, think about how your computer is working inside to let you do these tasks—just like how your brain is working to let you use the computer. It's all very Inception.



Want to see more?

Join our mailing list for updates, product news, free content, and more! You know you want to.





Related A&P posts:

Anatomy and Physiology: Relationships of the Respiratory System
Anatomy and Physiology: 5 Medical Myths Demythified!



Sources:

Visible Body 3D Human Anatomy Atlas 2
Brain: A Journal of Neurology
NatGeo's Brain Facts, News, and Photos
